X/Y/Z axes adopt 35MM heavy-duty ball screw guides, which have wider Z-axis sliding tables and larger X-axis slide block spacing compared with the M series. This results in less swing and higher precision in the machining process of the machine tool.
The φ120MM electric spindle is optimized for processing aluminum, copper, insulation, and bakelite boards.
All sheet metal parts above the water basin are made of stainless steel, enhancing the rust-resistant ability of the machine tool when using tap water as coolant.
The NK500 control panel provides direct access to commonly used functions with a single button press, saving on operational time. Additionally, the panel is rotatable, optimizing workshop space utilization.
An optional air-floating vacuum table is available, making fine adjustments easier during material loading.
The 16-tool magazine is compatible with single, dual, and four spindles, allowing for even distribution based on the number of spindles installed.
